The Shelly Wave Z-Wave Dimmer is a smart lighting controller module that allows precise, reliable dimming of compatible light loads, integrated into a Z-Wave smart home ecosystem. It offers both remote automation via a Z-Wave hub and manual control via physical wall switches, enabling flexible lighting control for homes or commercial spaces.
Shelly Wave devices work with over 4000 Z-Wave certified devices and gateways, using the latest Z-Wave 800 Series chipset.
Shelly Wave Dimmer is retrofit-able and designed to fit behind any switch or socket, instantly transforming it into a smart one. Once installed, include it in your Z-Wave network (Z-Wave gateway is required) and control connected lighting from anywhere using your smartphone or tablet.
Beautiful light.
Easy to install.
By a licensed electrician.
Add Shelly Wave Dimmer to your Z-Wave system. It will make your lights smart. It makes them responsive. It gives you the ability to control them, schedule, dim them and brighten them.
All of this control and intelligence comes from having an electrician wire the Shelly Wave Dimmer behind your existing light switch… in minutes.
Neutral wire optional.
Note: A Shelly Dimmer Bypass my be required in a 2-wire (no neutral) install – or if the total load is less than 20W.
Any switch…
Shelly Wave Dimmer has been designed to work with virtually any light switch typically found in homes… new or old. It installs invisibly behind them, enhancing their functionality instead of completely replacing it. Smart, affordable and convenient.
Any light fitting…
Shelly Wave Dimmer can turn virtually any dimmable light into smart lighting.
There is no need to change your light fittings or globes, saving you money and providing you the freedom to express yourself with the lighting of your choice… just the way you like it.
Compatible.
Using unique algorithms, Shelly Dimmer automatically recognises the type of light bulb used and calibrates to it perfectly.
LED
Fluorescent
Halogen
Incandescent
CFL
Like magic.
With Shelly Dimmer and the power of Z-Wave, your lights can turn on when motion is detected, by voice, app control or schedule.
You are in full control.
The finer details
Power supply:
220-240 V Ì´ 50 Hz
Power consumption:
< 0.3 W
Max. switching voltage AC:
240 V
Max. output power:
200W
Dimming type:
Trailing edge
Power measuring:
Yes
Overheating protection:
Yes
Overcurrent protection:
Yes
Overvoltage protection:
Yes
Internal-temperature sensor:
Yes
Distance:
Up to 40 m indoors (131 ft.) (depends on local condition)
Z-Waveâ„¢ repeater:
Yes
CPU
Z-Waveâ„¢ S800
Z-Waveâ„¢ frequency bands:
919.8 MHz (Australia & New Zealand)
Max. radio frequency power:
< 25 mW
Size (H x W x D):
37x42x16mm
Weight:
25 g.
Screw terminals max. torque:
0.4 Nm / 3.5 lbin
Conductor cross section:
0.2 to 2.5 mm² / 24 to 14 AWG (solid, stranded, and bootlace ferrules)
Shell material:
Plastic
Color:
Green
Ambient temperature:
-20°C to 40°C / -5°F to 105°F
Humidity:
30% to 70% RH
Max. altitude:
2000 m / 6562 ft.
