4 relays up to 16A each.
Wi-Fi or Ethernet
Connect Shelly Pro 4PM directly to your network. No Smart Hub required.
DIN Rail mountable
Shelly Pro 4PM provides precise monitoring of the power consumption of connected loads.
Extremely fast processor
MQTT and WSS support, TLS and custom certificates support for a broad range of use.
Improved API interface
From anywhere in the World.
With Shelly Pro 4PM you can automate up to 4 lighting circuits and almost any electrical appliances and control them remotely. Shelly Pro 4PM can even control appliances with large loads (up to 16A) which makes it perfect for kitchen appliances and domestic systems monitoring and control.
You can now monitor and analyse the power consumption of your electrical appliances and lighting. Shelly Pro 4PM has an integrated precise power meter that allow you to measure the power consumption and features free data storage for analysis. Help save the environment and save money.
The true power of a smart home is in the automations. Not having to touch your phone or use your voice assistant. Shelly Pro 4PM will allow you to automate your lights and appliances on a schedule or when certain conditions around your home are met (e.g. when your Shelly Door / Window Sensor is triggered).
Shelly is an open platform. With the embedded web server and HTTP commands, Shelly can be made compatible with your home automation systems and projects… securely and easily.
The finer details
|Power supply AC:||110-230V ±10%, 50/60Hz|
|Power supply DC:||No|
|Maximum load:||Up to 16A per channel with up to 40A for the whole device|
|Device power consumption:||< 4 W|
|DIN Rail mountable:||Yes|
|Roller shutter mode:||No|
|Device temperature protection:||Yes|
|Working without a neutral wire:||No|
|Control channels:||4 On/Off Relay Channels|
|Operational temperature:||-20°C to + 40°C|
|Local and smart control:||Yes|
|Built-in weekly scheduler:||Yes|
|Wi-Fi protocol:||802.11 b/g/n|
|Radio frequency:||2400 – 2500 MHz|
|Radio signal power:||1mW|
|Wireless range:||up to 50 m outdoors and up to 30 m indoors (depending on the building materials)|
|Size:||90mm x 52mm x 57mm|
