Up / Down.
Open / Close.
Automate* and remotely control the position of roller shutters, blinds, windows, awnings, pool covers and other devices powered by bi-directional 240V AC motors.
*Requires a Z-Wave compatible hub or software.
Z-Wave operated
Compatible with all certified Z-Wave gateways and features the latest 800 series chipset.
Extended wireless range
Up to 40m indoors and acts as a Z-Wave signal repeater for other Z-Wave devices.
Bulletproof security
S2 (Security 2) AES 128 encryption for the ultimate in security of your Z-Wave network.
Easy setup
SmartStart for easy inclusion into your Z-Wave system – scan the QR code and you are done.
High reliability
Communicates wirelessly on your dedicated Z-Wave mesh network – far removed from Wi-Fi.
Associations
Establish direct communication between Z-Wave devices which work even if your hub fails!
Power monitoring
Measure in real-time and log the power consumption of the connected load.
Z-Wave.
Works with any Z-Wave gateway or software.
Shelly Qubino devices work with over 4000 Z-Wave certified devices and gateways, using the latest Z-Wave 800 Series chipset.
Shelly Wave 1 is retrofit-able and designed to fit behind any switch or socket, instantly transforming it into a smart one. Once installed, include it in your Z-Wave network (Z-Wave gateway is required) and control connected appliances and lighting from anywhere using your smartphone or tablet.
Home Assistant Green
The affordable Home Assistant Green is the easiest way you can start using Home Assistant - The World's most popular open-source smart home software. It's plug-and-play hardware is perfectly tuned to make sure you get the most out of the pre-installed Home Assistant software. More than 1,000 built-in integrations support hundreds of thousands of smart devices and online services, with more regularly added by the HA community.
Aeotec Smart Home Hub
The Aeotec Smart Home Hub (works as a SmartThings hub) enables you to automate and control a huge range of smart devices and make them work in unison to create a seamless smart home. The hub utilises Matter, Zigbee, Z-Wave and Wi-Fi protocols. The SmartThings app for iOS and Android enables monitoring and control of your connected devices from anywhere. You'll also receive alerts from connected devices when there is unexpected activity. Voice control is available via Alexa and Google Assistant. 20% OFF - Limited time only.
Aeotec Z-Wave USB Z-Stick 7
The new Aeotec Z-Stick 7 (700 series) is a Z-Wave USB dongle designed to work with the all of the most popular automation software solutions, including openHab and Home Assistant. When attached to a host processor (PC, Raspberry Pi, etc), it becomes a Z-Wave communication device, which allows Z-Wave software to communicate with your Z-Wave devices.
Homey Bridge
Homey Bridge combines all your wireless and smart home devices into a single, easy-to-use smart home system. With over 50,000 smart devices supported, your home will not only be smarter... it will also be unified into one clever, more secure and comfortable home. Homey Bridge includes chipsets to support Z-Wave, Zigbee, Wi-Fi, 433 MHz and Infra-red - making it the most complete and compatible smart home hub in the World. Add up to 5 devices free... or go Premium for $4.49 per month for unlimited devices and access to Homey Insights, Logic & Variables.
Homey Pro (2023)
The all-new Homey Pro is the world's most advanced smart home hub. Supporting all smart wireless technologies including Wi-Fi, Z-Wave Plus, Bluetooth, Zigbee, 433 MHz, Infrared, Thread & Matter allowing for support of over 50,000 popular smart devices and services. Private, local, secure and powerful - Control, automate and monitor your entire smart home with Homey Pro.
Fibaro Z-Wave Home Center 3 Lite
The new Home Center 3 Lite is a smaller version of the most advanced smart home hub in the world. This clever smart home controller has been modelled on the solutions used in the popular Home Center 3 platform. This central unit can be connected with other Z-Wave devices which you can use while controlling electronics and household appliances, lighting, blinds, HVAC, alarm or watering system - with just a single button, app, gesture or word. Home Center 3 Lite is recommended for smaller smart home installations.
Fibaro Z-Wave Home Center 3
The new Home Center 3 is the most advanced and versatile smart home management controller in the World. Supporting Z-Wave Plus, Zigbee, Bluetooth LE, WiFi (b/g/n/ a ac) and 433 MHz wireless standards. A truely modern and reliable device that will allow full control of your smart home - a simple press of a button, a gesture or a word makes your smart home come alive.
Schedule.
Curtains and blinds that follow your daily routine.
Program your daily routines to perfection by synchronising Wave Shutter with your regular morning and evening activities. Have your curtains open and close at your chosen hours every day, establishing an ideal ambience to start and end your day. Use position control to dictate your preferred curtain position, customising your lighting levels to your exact liking.
Control.
From the couch… or from halfway around the World.
Open or close your blinds via your Z-Wave hub’s app, voice control, Z-Wave remote control or manually from the wall switch… the choice is yours.
Automate.
Let your awnings follow the weather
By creating associations between the Wave Shutter and other Z-Wave devices, they can communicate directly without a gateway. For example, you can connect Wave Shutter with a Z-Wave wind sensor/weather station. When strong wind is detected, your awnings will automatically close to avoid damage.
Secure.
Enhance the security of your home with smart scenes
Enhance your home’s safety by integrating Wave Shutter with other devices to establish a “Vacation Scene.” When you’re away, your window coverings will adjust automatically at pre-determined times daily, and both indoor and outdoor lights will randomly illuminate every evening. This will give the impression that someone is at home, deterring potential intruders. Secure peace of mind along with your property, even when you’re miles away.
The finer details
| Power supply: | 110–240 V AC ±10% |
| Power consumption: | < 0.3 W |
| Power measurement [W]: | Yes |
| Max switching voltage AC: | 240 V |
| Max switching current AC: | 10 A per channel |
| Overheating protection: | Yes |
| Overcurrent protection: | Yes |
| Distance: | up to 40 m indoors (131 ft.)(depends on local condition) |
| Z-Wave repeater:: | Yes |
| CPU: | Z-Wave S800 |
| Z-Wave frequencies band(s): | 919,8 MHz (Australia & New Zealand) |
| Max. radio frequency power: | < 25 mW |
| Size (H x W x D): | 37 mm x 42 mm x 16 mm ± 0.5 mm / 1.46 in x 1.65 in x 0.63 in ± 0.02 in |
| Weight: | 29 g / 1.02 oz. |
| Mounting: | Wall console |
| Screw terminals max torque: | 0.4 Nm / 3.5 lbin |
| Conductor cross section: | 0.5 to 1.5 mm? / 20 to 16 AWG |
| Conductor stripped length: | 5 to 6 mm / 0.20 to 0.24 in |
| Shell material: | Plastic |
| Color: | Black |
| Ambient temperature: | -20°C to 40°C / -5°F to 105°F |
| Humidity: | 30% to 70% RH |
| Max. altitude: | 2000 m / 6562 ft. |
